Imbalances between power generation and consumption lead to voltage and frequency fluctuations in the power grid. To date, these fluctuations have been offset by the existing balancing energy markets at the level of the transmission grids. With the increasing share of renewable energy in the power supply, the need for balancing increases sharply. As the majority of renewable energy is fed in at the distribution grid level, regional balancing mechanisms can reduce the need for balancing in the transmission grid and provide relief for the transmission grids.
In the project Flex4Energy, such a balancing mechanism is being created in the form of a Cloud-based trading platform to which providers of flexibility potentials can connect via a secure communication link. A flexibility potential is created, for example, through the installation of a storage system that is not permanently used to capacity in its primary application (e.g., load peak capping or buffering of a solar power system). During its idle times, the storage system can offer its services to the trading platform. The contribution margins thus generated improve the economic feasibility of the investment in the storage system.
The central instrument of the trading platform is a flexibility manager. The flexibility manager trades the flexibility potentials offered to the platform and tries to achieve an economic optimum for the respective providers. Another major novelty is the consideration of the current grid situation in the trading strategies, which is intended to avoid the situation that energy supplies between two trading partners lead to grid bottlenecks.
A very important issue for the project is security, especially the spatial and content-related protection of the information used against unauthorized access and attacks from the outside, secure communication, and the avoidance of instable operating states. This topic area is the responsibility of Fraunhofer IESE in Kaiserslautern.
A pilot of the trading platform in Flex4Energy is being run by HSE in Darmstadt. In addition to existing facilities, a storage system of the partner ads-tec (Nürtingen) will be offering flexibility potentials in the project. In this context, Fraunhofer ISE (Freiburg) is investigating the economic deterioration associated with the use of the storage system as a result of aging and derives prices from this that must be achieved in order to make use of the flexibility offered. Darmstadt University of Applied Sciences is in charge of developing the trading strategies of the flexibility manager. As the consortium leader, StoREgio is responsible for the overall project management. The project is supported by Project Management Jülich. The project volume is estimated at approx. 4 million euros.
